Feelteck-FT-810-Mix Value Counting and Sorting Machine

Specifications

• Fully automatic currency recognition and mixed value counting function with

high-quality fake notes detecting possibility

• Sorting and Non-stop counting with a reject pocket
• Well-accurate authentication strengthened by UV/MG/IR/MT sensors and both sides, upper and lower CIS scanners
• Up to 20 currencies Value discrimination with serial number recognition, reporting – printing**
• Various moods of counting – Fitness, Mix, Sort, Version, Face/Orientation, PCS, Multi
• Batch presetting function – Value batch and PCS batch
• Easy operations with color touch screen, user-friendly graphical UI notifications, and fully detailed, heavy-duty, durable keys
• Design of open channel for easy maintenance and cleaning
• New-improved roller friction feeding mechanism makes no jamming issues and the lowest noise while counting
• PC connection for software upgrade and saving all counted data to the computer
• Remote, external display, Report Printer**

Parameters

• Counting Speed: 800 to 1,200 Notes per Minute
• Hopper Capacity: 500 Notes
• Stacker Capacity: 200 Notes
• Reject Stacker Capacity: 80 pcs
• Display: 3.5″ TFT Touch LCD
• External Interface: RS232, RJ11, LAN,

USB Port and SD Card Slot

• Materials of bills: Paper and Polymer substrate
• Banknote size: 08 mm – 190x85x0.12 mm
• Power Supply: AC 100-240 V, 50~60 Hz
• Power Consumption < 50W
• Dimension : 280(W) x 260(D) x 315(H) mm
• Net Weight : 10Kg
